Swing over bed:360mm(14")or 410mm(16")
Swing over cross slide:215mm(8 1/2")or 255mm(10")
Swing in gap diameter x width:540(21 1/4")or 580(22")x190(7 1/2")
Height of center:185mm(7 1/2")or 205mm(8")
Distance between centers:1000mm(40")/1500mm
Width of bed:250mm(10")
Cutting tool max section:20x20mm(3/4"x3/4")
Total travel of cross slide:210mm(8 1/2")
Total travel of top slide:140mm(5 1/2")
Spindle bore:52mm(2")
Spindle morse taper in bore:M.T.NO.6
Spindle speeds mumber:16
Spindle speeds range:45~1800R.P.M
Threads inperial pitches:2~72T.P.I(45Nos)
Threads metric pitches:0.2~14mm(39Nos)
Longitudinal feeds inperial:0.002"~0.067"/Rev(17Nos)
Longitudinal feeds metric:0.05~1.7mm/Rev(17Nos)
Cross feeds imperial:0.001~0.0335"/Rev(17Nos)
Cross feeds metric:0.025~0.85mm/Rev(17Nos)
Range of module pitches:0.3~3.5MP(18Nos)
Range of diametral pitches:8~44DP(21Nos)
Total travel of tailstock quill:50mm(2")
Tailstock quill diameter:120mm(4 1/2")
Taper in tailstock quill:M.T.No.4
Spindle drive motor:4P/8P.3PH 3.3/2.2kw or 4.5/3kw
Coolant pump motor:4P,3PH 90W
Packing size(LxWxH):206(81")(256")x90(35 7/16")x164cm(64 9/16")
N.W/G.W.:1300kgs OR 1350kgs/1550kgs or 1600kgs;1500kgs or 1555kgs/1700kgs or 1755kgs
